Hi, I know next to nothing about ram overclocking.
I tried to do some research and do some carefully, but I would like suggestions.
What I have done:
Turn off RGB, based on XMP profile. I set the tCL,tRCD,tRP and tRas values indicated by the manufacturer as a maximum but increased the frequency from 3600 to 3666, set FCLK as 1833 and UCLK Div 1 Mode in UCLK = MEMCLK to try to maintain a 1:1 ratio
Read and review this:
It has been a great contribution, it helped me understand some things and I was able to see examples but due to lack of knowledge and inexperience I would not like to do more without asking. I noticed that in the Sheet, the number 122, is close to my situation but different die type (I think).
Objetive: Voltage < 1.45 Frequency ≈ 3800 CL <= 17
I uploaded an image with all the information but a summary:
CPU: R7 5700X
Ram: KLEVV CRAS X RGB [ 2×8 DDr4 3600 Cl18 ]
MB: Gigabyte b550m ds3h ac Rv 1.7
PD: Sorry if my writing is a little bad, English isn't my native language (Spanish) and I try to practice.
1 Comment
I would connect my computer case’s reset switch to the clear CMOS pins on the motherboard in order to recover from trial and error more easily. Then go download something called Thaiphoon Burner and run it, it will give you more information on your specific IC
