Hey!
Recently got my AM5 platform (Ryzen 7 7600, Asrock B650M Pro RS, Adata sticks with CL30 6000Mt/s EXPO, AX5U6000C3016G-DTLABBK). I’m very much a newbie with RAM OC so I spent a whole day looking at Actually Hardcore Overclockings videos, and used this one as a baseline: [https://www.youtube.com/watch?v=scjuMBClW18](https://www.youtube.com/watch?v=scjuMBClW18)
Current FCLK is 2100Mhz. I originally tried to go for 6200Mt/s with same timings and higher voltages (1.45v), was able to boot and do some memtesting, but eventually would get an error so had to lower for 6000, this setup is running stable but I’m really looking to inch a little bit more from the timing side as games like CS2 seem to benefit from it.
How are these results? I really would like to go for CL26 rather than 6200, but I’m unsure what to change next to make it stable. Any help will be greatly appreciated, thank you!
https://preview.redd.it/9jlnx2iz6fic1.png?width=539&format=png&auto=webp&s=36e94b468e780007b56425e2e6cf18b9f1fd9179
https://preview.redd.it/p65cd2iz6fic1.png?width=380&format=png&auto=webp&s=aefc9acbf53a0a23d46357440dc45bea0e4d6249
https://preview.redd.it/rcltroon8fic1.png?width=1119&format=png&auto=webp&s=96a78a63a161c06e545ff7629cf89bf4fb87f568
​
2 Comments
I’m relatively new to DDR5 overclocking as well and have been tuning a pair of similar Hynix-A dies. Here’s my [most recent stable settings](https://i.imgur.com/lbUfhx9.png) for reference. Had to bump up TRP and TRC by 2 to get 6200 MHz to work. Worth a shot on your end!
SOC voltage is one of the most important variables and you don’t have it mentioned or included in any pic (something on your PC seems to be breaking zentimings and ryzen master into not showing it)
Higher memclk and uclk like 6200, 6400 has lower latency and more bandwidth than 6000, so stuff like “I really would like to go for CL26 rather than 6200” doesn’t really make sense. 6000 is worse in every way.
You can highly likely achieve 6200 with uclk=memclk and GDM off with a sane SOC voltage like <=1.25v. Frequency is the foundation of the overclock, it’s one of the greatest variables for determining performance and you set everything else based on the frequency so if it’s going to be changed it has to be done at the start of the OC.
