CPU: AMD Ryzen 9 9850X3D
Asus B850-I latest bios
32gb 16×2 Klevv Crass V 6000MHz CL30 (M die I think)
240mm AIO
Formd T1 10L pc case
All fan set to 20% at 37db give or take till at full rpm at 92c.
Curve Optimizer Summary Setting Result
Curve Optimizer -19 Caused instability during memory stress tests
Curve Optimizer -18 Stable,
Final Curve Optimizer: -18 (All Core Negative Offset)
SoC Voltage Stability Tests (with Curve Optimizer)
SoC Voltage Curve Optimizer Result 1.23 V -19 AIDA failed 17 minutes
1.22 V -19 AIDA failed 48 minutes
1.22 V -18 AIDA failed 48 minutes
1.21 V -18 Stable
Final SoC Voltage: 1.21 V Final Curve Optimizer: -18
Memory Timing Stability Tests
tFAW Setting Result
tFAW 32 AIDA failed 17m 26s
tFAW 34 AIDA failed 5h 37m
tFAW 36 Stable
tWRWRSCL Setting Result
tWRWRSCL 19 AIDA failed 1h 40m
tWRWRSCL 20 AIDA failed 4h 29m
Final tWRWRSCL: 20
tRFC1 Setting Result
tRFC1 530 AIDA failed 4h 03m
tRFC1 540 Stable
Final tRFC1: 540
FCLK Frequency Setting Result FCLK 2167 MHz AIDA failed 2h 36m
FCLK 2133 MHz Stable
Final FCLK: 2133 MHz
Final Stability Test Test Result y-cruncher VT3 Passed 3h 12m AIDA Memory Stress Test Passed >5h
Final Stable Configuration Setting Value
Memory Speed 6200 MT/s
UCLK Mode UCLK = MEMCLK (DIV1)
FCLK 2133 MHz
Primary Timings 30-36-36-76 tRFC1 540
tRFC2 420
tFAW 36
tRDRDSCL 6
tWRWRSCL 20
tREFI 65535
SoC Voltage 1.21 V
Curve Optimizer -18 (All Core) Memory Context Restore Enabled Power Down Disabled
Benchmark Result
AIDA Memory Latency 68.4 – 68.5 ns
Cinebench R23 31111
Anything that can be changed or any room for OC?
(Reposted to a better viewing format)
