Built my first PC around 2 months ago.
GPU:6950xt
Motherboard: B650 Gaming AX X
Cooler: Cooler master 240mm AIO
CPU: Ryzen 7 7700x 8-Core procesor 16 threads
Ram: G skill 32GB 6000mhz
Cl 30-38-38-96(running expo)
CPU has a PPT limit of 85, using PBO and started with a negative curve of -25 for each core individually and a thermal limit of 85c.
These were my results
OCCT stresst test.
Single core effective clock performance test.
Testing 2 threads per core
Data set: Large || Mode: Extreme || Load type: Variable
Core 0 Effective clock
T1 T2 -25 cuve
5280-5445mhz 65c No errors 10minutes cycle
-30 curve
5326-5419mhz 61c no errors 10 minutes cycle
Core 1 Effective clock
T1 T2 -25 curve
5330-5362mhz 64c No errors 10 minutes cycle
-30 curve
5339-5382mhz 60c No errors 10 minutes cycle
Third cycle no errors
Core 2 Effective clock
T1 T2 -25
5290-5303mhz 68c No errors 10 minutes cycle
-30
5295-5392mhz mhz 65c No errors 10 minutes cycle
Core 3 Effective clock
T1 T2 -25
5330-5336mhz 64c No errors 10 minutes cycle
-30
5326-5415mhz 62c No errors 10 minutes cycle
Core 4 Effective clock
T1 T2 -25
5290-5308mhz 67c No errors 10 minutes cycle
-30
5289-5380mhz 67c No errors 10 minutes cycle
Core 5 Effective clock
T1 T2 -25 curve
5355-5457mhz 63c No errors 10 minutes cycle
-30 cuve
5339-5448mhz 83c Error 10 minutes cycle
Back to -25
5337-5380mhz No error 10 minutes cycle
Core 6 Effective clock
T1 T2
2min in; Error on logical core #16 with a -25
curve then changed to -20(5min in; second error same logical core) changed to
-15 curve
5181-5236mhz 86c no error 10 minutes cycle
Third cycle; Error core#6 logical core #16
fourth error now
Back to -10 curve
5096-5205mhz 64c No error
Core 7 Effective clock
T1 T2 -25
5280-5298mhz 66c No errors 10 minutes cycle
-30
5286-5317mhz 62c 10 minutes cycle no error
OCCT Multicore threaded performance test
4.7ghz 72cc max temp reached, 10min test.
Cinabech CPU multicore 4.8ghz 62c max temp reached score 18,866 on 10 minutes test
With stock settings is reached 4.9-5ghz at around 95c, cinabech score was 19,567, on 10 minutes test.
Spent days looking around the internet for way to improve 7700x temps, I had 0 experience and finally achieved it, my fans are not that noisy now 🙂
Still have two questions for the ones with a wider knowledge.
1. Will this change affect the life of my cpu?
2. Can it cause damage in the long term?
