Motherboard is Gigabyte Z890M Aorus Elite
+45 mV to P and E cores
P-cores can do 5.6 GHz all core
E-cores can do 5.0 GHz all core
42 ring / 30 NGU / 30 D2D
0.77 V VNNAON, 1.05 V VCCSA, 1.15 V ring
2×8 GB DDR5-8000 36-48-46-92, tRFC 480, tREFI 90000, 1.45 VDD, 1.40 VDD2, 1.40 VDDQ
210W PL1 and PL2
Unleashed preset
Turbo load line calibration
